TPU Lining Hose
Jacket: 100% virgin high tenacity polyester Jacket, Double Jacket, circular woven twill weave or plain weave.
Lining: TPU tube, raw materials approved by NSF,
Application: Potable Water Transfer
Standard length: 15m (50ft), 30m (100ft)
I.D. | Service Pressure | Minimum Burst Pressure | |
inch | mm | Psi/bar | Psi/bar |
2” | 50 | 250/17, 300/21, 400/28 | 750/51, 900/63, 1200/84 |
2 1/2” | 65 | 250/17, 300/21, 400/28 | 750/51, 900/63, 1200/84 |
3” | 75 | 250/17, 300/21, 400/28 | 750/51, 900/63, 1200/84 |
4” | 102 | 250/17, 300/21 | 750/51, 900/63 |
5” | 127 | 250/17, 300/21 | 750/51, 900/63 |
6” | 152 | 250/17, 300/21 | 750/51, 900/63 |
Aquatran Premium NSF 61 Approval
TPU Covered Hose
Cover and Lining: TPU tube, smooth cover
Reinforcement Jacket: High tenacity synthetic jacket
Application: Potable water transfer
Standard length: 15m (50ft), 30m (100ft), 200m (660ft)
I.D. | Service Pressure | Minimum Burst Pressure | |
inch | mm | Psi/bar | Psi/bar |
2” | 50 | 250/17, 300/21 | 750/51, 900/63 |
2 1/2” | 65 | 250/17, 300/21 | 750/51, 900/63 |
3” | 75 | 220/15, 250/17 | 660/45, 750/51 |
4” | 102 | 150/10, 200/14 | 450/30, 600/42 |
5” | 127 | 150/10, 200/14 | 450/30, 600/42 |
6” | 152 | 150/10, 200/14 | 450/30, 600/42 |
